Extreme Flight 74" Slick 580 EXP- Red/White/Blue


טיסן 3d למנועי 35-40 סמ"ק.

המלאי אזל

קטגוריות: , מק"ט: 366RW



Wingspan: 74 inches
Length: 71.5 inches with spinner
Width of elevator/stabilizer: 30 inches
Height of the rudder sitting on the tailwheel: 19 inches
Wing area: 1070 square inches
Weight: 10.5-11 lbs.

Gas Power System

DA 35
12-14 oz. FlowMaster fuel tank
EF Fuel Dot

Electric Power System

Xpwr 30cc electric motor
Castle Creations Edge HV-80 electronic speed control
19 x 8, 19 x 10, or 20 x 8 electric prop
Blazing Star Electric Standard EXTRA LONG Standoff
12 S (x2 6S) 3000-3700 mAh batteries

Spinner3.5 inch


Qty. 4 full size, metal gear hi-torque servos. MKS HV-1220 recommended.
Qty. 1 throttle servo, we used a metal gear 13g for the manual build. MKS HV-1250 recommended.

Servo Arms

Qty. 2 Extreme Flight 1.5" single servo arms (tapped 3mm) for ailerons
Qty. 1 Extreme Flight 2" single servo arms (tapped for 3mm) for elevator
Qty. 1 Extreme Flight 4" double servo arm (tapped for 3mm) for pull-pull rudder

Servo Extensions

Qty. 4 Extreme Flight 20 AWG 6" servo extensions for ailerons
Qty. 1 Extreme Flight 20 AWG 24" servo extensions for elevator
Qty. 1 Extreme Flight 20 AWG 12" servo extension for throttle servo or ESC

Using design and construction technology from Jase Dussia's 120CC Slick 580 EXP, the 74" features a new generation of light, strong EXP construction. We've radically expanded the use of composites, drawing on our experience from 120CC, which has allowed us to create a highly styled appearance along with very light weight.

For gasoline power, we recommend the DA-35 engine, and we have pre-marked the firewall for this engine. Many gas engines 30-35CC are appropriate, and the firewall also has "crosshair" markings to align these various templates. If installing the DA-35, the standoffs included with the engine are the correct length. A 12, 14, or 17 oz. Extreme Flight Flowmaster fuel tank is recommended.

For electric power, we recommend the XPWR 30CC brushless outrunner motor and an 80-120 amp HV ESC, providing approximately 3000-3200 watts. Our choice is the Castle Creations Edge series. The 74" Slick 580 airframe is equipped with a custom mounting location for the Edge controllers. With the XPWR 30CC, we recommend 12S 3000-3700mah lipo batteries and a 19×8, 19×10, or 20×8 electric prop.

Extreme Flight BlazingStar STANDARD EXTRA-LONG adjustable standoff kit to perfectly mount the XPWR 30CC motor into this airframe or anywhere sized for a DA-35 installation. The firewall of the 74" Slick 580 EXP is also pre-marked for the XPWR 30CC bolt pattern to add convenience.

The Slick 580 EXP requires 4 full-size metal-gear servos, 275 oz-inches or more recommended. We tested with MKS HV1220 servos. If using gas power, add one servo for throttle control, which does not need to be high torque, although high speed is beneficial.

The spinner size is 3.5 inches diameter. Note that the XPWR 30CC requires a perimeter-bolt style spinner or a center-bolt adaptor.

The 74" Slick 580 borrows tech from Jase Dussia's 120CC Slick, and has been further targeted to maximize 3D stability. This is a rock-solid low-and-slow 3D platform that could easily be a 3D trainer, while retaining the abilities of its competition-winning big brother. It has very low coupling, no rock, and excellent manners, while snapping and spinning precisely and sharply. To quote Chris Hinson, CEO and chief test pilot of this project: "It 3D's like the best Edge, and has the precision of the Slick."
