Freewing F-22 Raptor Ultra Performance 8S 90mm – PNP

3,150

טיסן סקייל 1:13

  • כולל סכימה מדוייקת, מתקפלים בעלי בולמי זעזועים
  • כולל מדפים, מערכת תאורה, אבזור עשיר ועוד
  • הרכבה פשוטה ומהירה





קיים במלאי

קטגוריות: , מק"ט: FJ31321P

תיאור

Specifications:

Model Scale: 1:13 Scale
Wingspan: 1060mm
Length: 1500mm
Empty Weight: 2960g
CG (Center of Gravity): 150mm (5.9") from the leading edge of the wing at the root
Power System: 8S 4075-1390Kv Inrunner Brushless Motor
Electronic Speed Control: 150A, EC5 Connector
Propeller / EDF: 90mm 12-Blade EDF
Servos: 9g hybrid digital standard with 300mm lead : nose gear steering – MD31093-300
             9g hybrid digital standard with 400mm lead : nose gear door – MD31093-400
             17g metal gear digital standard with 100mm lead : left rudder, right rudder – MD31172-100
             23g metal gear digital reverse 100mm lead : right elevator – MD31231R-100
             23g metal gear digital standard 100mm lead : left elevator – MD31231-100
             17g metal gear digital standard with 200mm lead : left flap, right flap – MD31172-200
             17g metal gear digital standard with 300mm lead : left aileron, right aileron – MD31172-300
Landing Gear: Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts
Required Battery: 6 Cell 22.2V 5000 mAh LiPo and 2 Cell 7.4V 5000 mAh LiPo batteries with EC5 connector in series
– OR –
Two 4 Cell 14.8V 5000 mAh LiPo batteries with EC5 connector
Required Radio: 6 Channel (required)
Ailerons: Yes
Elevator: Yes
Rudder: Yes
Flaps: Yes
Lights: Yes
Hinge Type: Nylon Reinforced
Material: EPO Foam
Skill Level: Intermediate/Advanced/Expert
Build Time: 3-4 Hours
Recommended Environment: Outdoor

The F-22 Raptor is the world’s first Fifth Generation fighter, and its technology and performance continue to set the standard against which all other fighter jets are judged. The Freewing F-22 is a flying RC replica of this innovative fighter jet. Boasting both the lowest stall speed and one of the highest top speeds among all of Freewing’s jets, this super scale F-22 is capable of executing maneuvers most other EDFs can only dream of –our design team considers it a Performer and a Trainer in one!

The Freewing F-22 is available in two PNP versions. The Standard version features a 90mm EDF with an all-new 9 blade single piece impeller, 3748-1750Kv outrunner brushless motor and 130A ESC. The Deluxe 8S version features a 90mm 12 blade impeller mounted to a powerful 4075-1390Kv inrunner brushless motor and 150A HV ESC. The F-22’s maximum level airspeed exceeds 170KPH / 106MPH and 190KPH / 119MPH between the Standard and Deluxe versions, respectively.

Overall, the Freewing 90mm F-22 is a very approachable flyer and suitable for pilots moving up to their first 90mm jet from a smaller 70mm or 80mm jet. For pilots already familiar with the handling of a 90mm jet, the Freewing F-22 offers the potential to master an expanded set of realistic maneuvers.

Features:
Model officially licensed by Lockheed Martin
Exceptional low speed stability and high speed agility
Realistic Scale Maneuver capability includes Cobra, Mongo Flip, J-Turn, Descending Spiral, Hover, etc
Efficient, balanced, powerful 12-Blade EDF power system with coveted realistic "woosh" jet sound
Has the lowest stall speed and one of the highest top speeds among all of Freewing’s jets
Large battery bay to easily fit either 6S or 8S battery (for appropriate 6S or 8S Power System)
Materials include EPO foam, aluminum, carbon fiber, steel, nylon, plastic, and wood for maximum durability
Features a mixture of sharp panel lines, graduated paintwork, and realistic decals for maximum realism
MultiShade™ livery incorporating paint and decals with over 12 different colors and subtle shading in metallic, satin, and matte finishes
Servos are housed within plastic trays for easy removal and servicing
Cockpit is lined with thin plastic to resist heat damage
Grass-capable suspension landing gear and sequenced nose gear doors with magnet assist
Main wings disconnect conveniently with a flexible ribbon wire cable, which smartly reduces the load exerted on the actual electronic connections
Magnetic nose cone encased in molded plastic with raised surface details can be removed easily to reduce the model’s length during transport to your flying field
MFCB for wire organization and future expansion-potential with LEDs and optional accessories
Widened gear stance and larger-than-scale grass-appropriate wheels greatly improve ground handling on short grass runways
Ball Bearing-supported horizontal stabilators
Screw-assembly for all flying surfaces
Capable of Expert-level maneuvers as well as smooth, stable slow flight for less-experienced jet flyers

Includes:
Freewing F-22 Raptor Ultra Performance 8S 90mm EDF Jet – PNP
12-Blade EDF power system (installed)
4075-1390Kv inrunner brushless motor (installed)
150A ESC with EC5 connector (installed)
Electronic retractable landing gear (installed)
Servos, LED Lights (installed)

Requires:
6 Channel radio – minimum 6 channel radio
6 Channel receiver – minimum 6 channel receiver
TWO 4 Cell 14.8V 6000 mAh LiPo batteries with EC5 connector
– OR –
ONE 6 Cell 22.2V 5000 mAh LiPo battery with EC5 connector AND ONE 2 Cell 7.4V 5000 mAh LiPo with EC5 connector – EPR50006 AND EPR50002E
EC5 2-to-1 series adapter
4 Cell compatible battery charger – minimum 4 cell (4S) charger
