Specifications
Wingspan: 70 inches
Length: 70 inches
Wing Area: 1000 square inches
Weight: 9.5-10.5 pounds
Electric Power System
Xpwr 30cc electric motor
Blazing Star XL Standoff Set
Castle Creations Edge HV-80 ESC or HV-120 ESC
Electric beechwood electric propeller: 20 x 8, Xoar PJN
Battery: (2) 6S 3300-3700 mAh
Gas Power System
Desert Aircraft DA 35
Desert Aircraft DA 35 muffler
Falcon 20 x 8 carbon prop
FlowMaster 12 or 14 oz. fuel tank
EF Fuel Dot
Spinner
EF 3 inch carbon spinner with aluminum backplate or EF Elite spinner
Radio
Modern computer radio
Servos
Qty. 4 full size, metal gear hi-torque servos. MKS HV-1220 recommended.
Qty. 1 throttle servo for gas setup, MKS HV-1250 recommended.
Servo Arms
Qty. 2 Extreme Flight 1.5 inch single servo arms (tapped 3mm) for ailerons
Qty. 1 Extreme Flight 1.5 inch single servo arms (tapped for 3mm) for elevator
Qty. 1 Extreme Flight 3 inch double servo arm (tapped for 3mm) for pull-pull rudder
Servo Extensions
Qty. 2 Extreme Flight 20 awg 3 inch ( Rx to wing root)
Qty. 2 Extreme Flight 20 awg 6 inch (wing root to Aileron servo)
Qty. 2 Extreme Flight 20 AWG 24 inch for Elevator and Throttle servo or ESC
70" Extra 300- EXP V2 Orange/Blue/White
The Extreme Flight 70" Extra 300 EXP was a huge hit among our customer base when it was originally released several years ago, packing an amazing amount of performance into an easy to transport, affordable airframe. We thought it was high time to bring it up to the modern specifications of our other 30cc aircraft. As such the 70" Extra 300 EXP V2 now shares the ultra lightweight and rugged laminated composite construction of our other current airframes and the 2 mini servos previously used for elevator actuation on the V1 version have been replaced with a single high torque standard size metal gear servo, making set up even easier. The V2 version also features the self aligning stab feature that has become so popular on our recent releases. The performance capability of the Extreme Flight RC Extra 300 EXP v2 is phenomenal! This sleek, fast and agile airframe is completely unlimited in its ability to perform the full range of full stall high alpha maneuvers and aggressive gyroscopic tumbling maneuvers. The Extra is also a top notch precision and XA aerobatic machine.
